The LES-241L60@80@120-PS stands out with its active early - warning system. Using sophisticated sensors and intelligent algorithms, it continuously monitors the electrical parameters of the system. This includes real - time tracking of voltage, current, temperature, and power consumption.
As soon as it detects any abnormal changes or signs of potential failures, the system immediately sends out alerts. Whether it's an impending overload, a short - circuit risk, or an overheating component, the early - warning feature gives operators precious time to take proactive measures. This not only prevents costly breakdowns but also minimizes the risk of electrical accidents, ensuring the safety of both personnel and equipment.
| Model | LES-241L120-PS | LES-241L80-PS | LES-241L60-PS | ||
| Battery Parameters | |||||
| Charge/Discharge Rate | 0.5C | 0.33C | 0.25C | ||
| Rated Voltage [V] | 768 | ||||
| Operating Voltage Range [V] | 672~876 | ||||
| Rated Cell Capacity [Ah] | 314 | ||||
| Rated Capacity [kWh] | 241.152 | ||||
| Configuration | 1P240S | ||||
| PV Parameters | |||||
| Max. PV Input Power [kW] | 60×4 (Optional) | 60×3 (Optional) | 60×2 (Optional) | ||
| Max. PV Input Voltage [V] | 200~660 | ||||
| Number of MPPTs / Max. Strings per MPPT | 4/1 | 3/1 | 2/1 | ||
| Max. Input Current per MPPT [A] | 150 | ||||
| AC Parameters (On Grid) | |||||
| Rated Output Power [kW] | 120 | 80 | 60 | ||
| Rated Output Current [A] | 173 | 115 | 87 | ||
| Rated Grid Voltage [V] | 3W/N/PE,230/400 | ||||
| Rated Grid Frequency [Hz] | 50/60 | ||||
| Power Factor | 1 (0.9 leading to 0.9 lagging) | ||||
| THDi | ≤3% (at rated power) | ||||
| AC Parameters (Off-Grid) | |||||
| Rated Output Power [kW] | 120 | 80 | 60 | ||
| Rated Output Current [A] | 173 | 115 | 87 | ||
| Rated Output Voltage [V] | 400 | ||||
| Rated Output Frequency [Hz] | 50 | ||||
| Unbalanced Load Capability | 100% | ||||
| General Parameters | |||||
| Ingress Protection Rating | IP54 | ||||
| Communication Method | RS485, Ethernet | ||||
| Communication Protocol | Modbus | ||||
| Operating Temperature Range [°C] | -20~+50 | ||||
| Cooling Method | Battery Compartment (Liquid-Cooled)/ Electrical Compartment (Air-Cooled) |
||||
| Fire Protection System | Aerosol,Water Fire Protection | ||||
| Max Altitude [m] | 4000 (>2000 Derating required) | ||||
| Transportation Method | Integral transportation | ||||
| Relative Humidity | 0~95%, Non-condensing | ||||
| Dimensions(W*D*H) [mm] | 700+ 2600 | ||||
| Weight[kg] | 650×1000×2350+ 1000×1330×2350 | ||||
